Fortpro Air Spring Replacement for 1R12-487 & 9366 | F245570 | Heavy Duty Suspension Upgrade for Trucks & Trailers | Perfect for Off-Roading & Towing Applications

Fortpro Air Spring F245570 is a premium quality air suspension systems designed to provide exceptional performance in commercial and cargo vehicles. These air spring suspensions offer the perfect combination of comfort, stability and improved load capacity.

Specifications:

• Brand: Fortpro
• Part Type: Air Spring / Air Spring Bag / Suspension Air Spring
• Vehicle Type: Semi-Trucks, Heavy-Duty Trucks
• Part OEM: 9366, W013589366, W01-358-9366
• Position: Primary Truck & Trailer Axle
• Air Spring Style: 1T Reversible Sleeve
• Piston Type: Composite
• Bead Plate Diameter Bottom: 9.75"
• Bead Plate Diameter Top: 9.00"
• Collapsed Height: 5.50"
• Max. Height: 15.00"
• Part Diameter: 10.12"
• Piston Height: 3.75"
• Stud Configuration-Bottom: 1
• Stud Configuration - Top: 2
• Weight:: 11.82 lbs
• Application: Holland (Neway) 90557160, 90557210, 90557225, Watson & Chalin AS-0054, Wabash Holland (Neway) 90557225
• VMRS: 016-008-000

CrossReference:

• Automann: 566CT64459, AB1DK23H9366
• Contitech: 91012A488, 91012P488
• Dayton Parts Batco: 1R12487, 3529366
• Firestone: 9366, W013589366, W01-358-9366
• Goodyear: 1R12487, 1R12487
• Meritor: FS9366, MAF9366
