Fortpro Air Spring Replacement for 8204, 1R12 508 | F245590 - Heavy Duty Suspension Upgrade for Trucks, Trailers & RVs

Fortpro Air Spring F245590 offers exceptional load capacity for a wide range of applications, from commercial vehicles to trailers and recreational vehicles (RVs). Its high-quality construction and innovative design ensure superior strength and durability in any condition. Enjoy a smooth and stable ride thanks to the improved shock absorption capabilities of this air spring. Carefully designed and high-strength materials ensure a more comfortable driving experience, reducing vibrations and road shock.

Specifications:

• Brand: Fortpro
• Part Type: Air Spring / Air Spring Bag / Suspension Air Spring
• Vehicle Type: Semi-Trucks, Heavy-Duty Trucks
• Part OEM: 8204, W013588204, W01-358-8204
• Position: Primary Truck & Trailer Axle
• Air Spring Style: 1T Reversible Sleeve
• Piston Type: Composite
• Bead Plate Diameter Bottom: 9.50"
• Bead Plate Diameter Top: 9.00"
• Min. Height: 4.40"
• Part Diameter: 10.12"
• Piston Height: 2.83"
• Stud Configuration-Bottom: 1
• Stud Configuration - Top: 2
• Weight:: 10.43 lbs
• Application: Holland (Neway) 90557173 (RL196A-12) Holland (Neway) 90557223Binkley Newlite (NS 190-16)
• VMRS: 016-008-000

CrossReference:

• Automann: 566CT64456, AB1DK23H8204
• Contitech: 91012P484
• Dayton Parts Batco: 1R12508, 3528204
• Firestone: 8204, W013588204, W01-358-8204
• Goodyear: 1R12508, 1R12522, 1R12522
• Meritor: FS8204, MAF8204
