Fortpro Air Spring Replacement for 8713, 1R13-176 & F245591 - Heavy Duty Suspension Upgrade for Trucks, Trailers & RVs

Fortpro Air Spring F245591 is designed to offer exceptional performance in air suspension systems. With robust construction and durable materials, this air spring guarantees resistance and reliability in various conditions of use.

Specifications:

• Brand: Fortpro
• Part Type: Air Spring / Air Spring Bag / Suspension Air Spring
• Vehicle Type: Semi-Trucks, Heavy-Duty Trucks
• Part OEM: 8713, W013588713, W01-358-8713
• Position: Primary Truck & Trailer Axle
• Air Spring Style: 1T Reversible Sleeve
• Piston Type: Composite
• Bead Plate Diameter Bottom: 9.22"
• Bead Plate Diameter Top: 10.38"
• Collapsed Height: 8.00"
• Max. Height: 21.50"
• Part Diameter: 10.62"
• Piston Height: 5.38"
• Stud Configuration-Bottom: 1
• Stud Configuration - Top: 2
• Weight:: 15.20 lbs
• Application: Hendrickson Trailer S22948 (Van Traax)Prior to 9/99 - use 9525 piston with bumper spacer
• VMRS: 016-008-000

CrossReference:

• Automann: 566CT64636, AB1DK25E8713
• Contitech: 101016S533
• Dayton Parts Batco: 1R13176, 1R13263, 3528713, S22697, S22948
• Firestone: 8713, W013588713, W01-358-8713
• Goodyear: 1R13176, 1R13176
• Meritor: FS8713, MAF8713
